1. Introduction
Coriolis Mass Flow Meters type of CX-CMFI are the leading meters for precision flow measurement. And with good reason, the meters offer the
most accurate measurement available for virtually any process fluid, while exhibiting exceptionally low pressure drop. The meters offer direct mass flow,
volume flow, density, and temperature measurement of liquids and slurries — without the need for additional equipment, manual calculations, or estimations.
The meters are designed for unsurpassed performance in even the harshest operating environments. They have no moving parts, and any special mounting or
flow conditioning requirements. Every meter is available with stainless steel wetted parts and a wide variety of process connections to meet your every need.
The meters carry hazardous area approval for P. R. China.
2. Principles of Measurement
The structure of CX-CMFI Coriolis Mass Flow Meters was consisted of a pair of bended tubes. The principle is to detect Coriolis force forced a pair of tubes
from inner mass flow by fluid.
A new force—Coriolis force would be appear while two conditions met: (1) vibrating with normal frequency in a pair of bended tubes, (2) fluid flowing in tubes.
This force was produced upon synthesis from vibrating force and flowing force by fluid in tubes. And tubes would be wresting symmetric the center line because
the force forced. Two displacement sensors on sides of tubes detect the force and output electric signals. The signals regulated, mass flow directly produced.
3. Technical Specifications of Products
3.1 Technical Specifications
Table of Technical Specifications (Table 1)
| Titles | Technical Specifications |
| Mass flow accuracy | ±[0.2% +£¨zero stability /flow rate×100%£©] |
| Mass flow repeatability | ±(1/2) ×[0.2% +£¨zero stability /flow rate×100%£©] |
| Density range | 0.2 g/cm3¡«3.5g/cm3 |
| Density accuracy | ±0.002g/cm3 |
| Temperature range | -60¡æ¡«+200¡æ |
| Temperature accuracy | ±1¡æ |
| Output of current loop | 4mA¡«20mA |
| Output of frequency/pulse | 0Hz¡«10kHz |
| Contactor capacity of a Batch Control relay | 24V/0.1A |
| Contactor form | normal open |
3.2 Other Specifications
Environmental Specifications (Table 2)
| Titles | Specifications |
| Temperature range of fluid | -40¡æ¡«+200¡æ |
| Environmental temperature range | 0¡æ¡«+40¡æ |
| Environmental humidity | ≤90% RH, non condensation |
| Atmospheric pressure range | 86kPa¡«106kPa |
| Power supply of transmitters |
Essential safety Voltage: AC(220±10%)V,(50±5%)Hz Composite Voltage: DC (24±10%) V |
| Power consumed | £¼15W |
Specifications (Table 3)
| Specs | Line Sizes (mm) | Flow Range (t/h) | Calibration Range (t/h) | Max. Tube Pressure (MPa) | Zero Stability (t/hr) |
Velocity Parameter (h m/t s) |
| DN1 | 1 | 0¡«0.04 | 0.004¡«0.04 | 30.0 | 0.000008 | 353.7 |
| DN3 | 3 | 0¡«0.35 | 0.035¡«0.35 | 30.0 | 0.000067 | 39.3 |
| DN6 | 6 | 0¡«0.7 | 0.07¡«0.7 | 30.0 | 0.00016 | 19.65 |
| DN10 | 10 | 0¡«1.2 | 0.12¡«1.2 | 30.0 | 0.0002 | 4.912 |
| DN15 | 15 | 0¡«6.4 | 0.64¡«6.4 | 4.0 | 0.0011 | 2.183 |
| DN25 | 25 | 0¡«16 | 1.6¡«16 | 4.0 | 0.002 | 0.902 |
| DN40 | 40 | 0¡«40 | 4¡«40 | 4.0 | 0.003 | 0.334 |
| DN50 | 50 | 0¡«65 | 6.5¡«65 | 4.0 | 0.006 | 0.197 |
| DN80 | 80 | 0¡«160 | 16¡«160 | 2.5 | 0.01 | 0.0873 |
| DN100 | 100 | 0¡«250 | 25¡«250 | 2.5 | 0.015 | 0.0544 |
| DN150 | 150 | 0¡«550 | 55¡«550 | 2.5 | 0.03 | 0.0 |
3.3 Explosion-proof Identification Code
Teble of Explosion-proof identification code (Table 4)
| Form of Explosion-proof | Identification Code |
| Essential safety | Exib[ib]IIBT4 |
| Composite | Exdib[ib]IIBT4 |
